Combination SOG Bar Chairs

Combination SOG bar chair with wide base for slab-on-ground reinforcement

Combination SOG Bar Chairs

Combination Slab on Ground (SOG) bar chairs are engineered to support reinforcing mesh or bar in slab-on-ground, and precast applications. Each chair offers dual cover heights in a single unit, reducing SKU volume and simplifying specification on site. Manufactured from high-strength recycled plastic, these chairs are non-corrosive, AS/NZS 2425:2015 compliant, and specifically designed to avoid puncturing polymer membranes thanks to a flat contact base.

The stackable design enables efficient site handling, and the product is suitable for direct placement on plastic sheeting. An optional 200 mm base plate is available separately, enhancing stability for use on sand, soft ground, or uneven subgrades. The design accepts both mesh and bar reinforcement without deformation and maintains precise cover depth as required by engineering drawings. This product is tested for strength, dimension tolerance, and load capacity to meet construction-grade performance requirements.

Download Combination SOG Bar Chairs Brochure
Download Technical Data Sheet



SKU: N/A Categories: ,

Description





Specification

Combination SOG Bar Chairs

Product Code Description Bag Qty Pallet Qty
101457 Bar Chairs Combination SOG 25/40mm 100 5000
101458 Bar Chairs Combination SOG 50/65mm 100 5000
101460 Bar Chairs Combination SOG 75/90 100 5000
101462 Bar Chairs Combination SOG 85/100 100 5000

Base Plates

Product Code Description Bag Qty Pallet Qty
112528 Bar Chairs SOG Base Plate 200mm 100 3000

Tall Combination SOG Bar Chairs

Product Code Description Bag Qty Pallet Qty
101489 Tall Bar Chairs Combination SOG 105/110mm 100 3000
105033 Tall Bar Chairs Combination SOG 115/120mm 100 3000
107386 Tall Bar Chairs Combination SOG 125/130 100 3000
107387 Tall Bar Chairs Combination SOG 135/140 100 3000
101490 Tall Bar Chairs Combination SOG 145/150mm 100 3000



Key Features and Benefits

  • Dual-height design reduces inventory and improves placement flexibility on site.
  • AS/NZS 2425:2015 compliant for certified use in reinforced concrete applications.
  • Non-corrosive material prevents rust in wet environments and extends product lifespan.
  • Membrane-safe flat base eliminates risk of puncturing plastic underlays.
  • Optional 200 mm wide base enhances chair stability on soft or sandy subgrades.
  • Stackable for transport and storage, easing logistics across large pours.
  • Non-cliptop saddle accepts standard mesh or bar sizes without slippage.
  • Made from recycled plastic, aligning with sustainable site practices.
