Hydrotite

Hydrotite is a high-performance hydrophilic waterstop designed for effective waterproofing of construction joints in water-retaining and water-excluding concrete structures. Its co-extruded profile directs controlled expansion across the joint, allowing the Hydrotite waterstop to expand up to eight times its original volume when exposed to water, creating a reliable seal for concrete joints. Engineered for durability, it maintains consistent performance through repeated wet-and-dry cycles in demanding commercial and civil applications.

The self-adhesive backing simplifies installation and reduces labour time, while the delay coating prevents premature expansion during construction. This hydrophilic strip requires no site welding and installs using simple butt joins, improving on-site efficiency. Compatible with rough surfaces when used with Leakmaster gun-grade waterstop, Hydrotite also integrates with traditional PVC systems to deliver flexible waterproofing solutions across a wide range of concrete joint applications.

SKU: N/A Categories: ,

Specification

Product Code Description Pack Qty
105905 Hydrotite 7X25X10M Roll CJ0725-3K-AD 4 Rolls
105089 Hydrotite 20X20X10M Roll CJ2020-M 3 Rolls
111713 Hydrotite 30X30X10M Roll CJ3030-M 2 Rolls
108135 Hydrotite 30X10X10M Roll CJ1030-4M 4 Rolls
105907 Hydrotite 10X20X10M Roll CJ1020-2K-AD 5 Rolls
105906 Hydrotite 2X20X25M Roll DSS-0220-AD 4 Rolls
111714 Hydrotite 12mm x 10m Roll RSS1208D 2 Rolls
110124 Hydrotite 16mm x 10m Roll RSS1610D 2 Rolls
111038 Hydrotite 20mm x 10m Roll RSS2014D 2 Rolls
110125 Hydrotite 25mm x 10m Roll RSS2519D 2 Rolls

Key features and benefits

  • High Expansion Rate: Expands up to eight times its original volume upon water exposure, ensuring a secure seal.
  • Co-Extruded Design: Directs expansion across the joint for maximum sealing efficiency.
  • Self-Adhesive Backing: Facilitates easy and quick installation, reducing labour costs.
  • Delay Coating: Prevents premature swelling during construction, ensuring effectiveness when needed.
  • Durable Performance: Unaffected by repeated wet and dry cycles, ensuring long-term reliability.
  • Simple Installation: No site welding required; joints are connected via simple butt joints.
  • Versatile Application: Can be applied to rough surfaces and is compatible with traditional PVC waterstop systems.
  • Safe Material: Non-toxic and non-hazardous, suitable for various construction environments.
