Concrete Spacer

Concrete Spacer

Danterr’s Concrete Spacer with Tie Wire is a fibre-reinforced, high-compression square concrete spacer engineered to maintain precise cover for reinforcement bars in slabs, beams, columns, and precast elements. Designed with a tapered body for self-locking stability and a galvanised tie wire for secure fastening, it prevents shifting during pours and ensures even concrete coverage—essential for structural performance and longevity.

With compressive strength exceeding 60 MPa, these concrete bar spacer squares are ideal for heavy-duty slab-on-ground, suspended slab, and civil works. The large flat base distributes load evenly while the tapered profile resists displacement under pressure. Available in cover sizes from 20mm to 100mm, these concrete aspros are tested to comply with AS/NZS 2425:2015 and verified by NATA-accredited labs for performance reliability.

SKU: N/A Categories: ,

Specification

Product Code Description Pack Qty Pallet Qty
111689 Concrete Spacer 20mm with Gal Tie Wire 200 21600
110111 Concrete Spacer 25mm with Gal Tie Wire 100 14400
109377 Concrete Spacer 30mm with Gal Tie Wire 100 14400
107884 Concrete Spacer 35mm with Gal Tie Wire 50 5600
107383 Concrete Spacer 40mm with Gal Tie Wire 50 4800
111690 Concrete Spacer 45mm with Gal Tie Wire 50 4800
105796 Concrete Spacer 50mm with Gal Tie Wire 50 4000
107585 Concrete Spacer 55mm with Gal Tie Wire 50 4000
107867 Concrete Spacer 60mm with Gal Tie Wire 25 2250
107807 Concrete Spacer 65mm with Gal Tie Wire 25 2025
107333 Concrete Spacer 70mm with Gal Tie Wire 25 2025
107848 Concrete Spacer 75mm with Gal Tie Wire 25 1800
108594 Concrete Spacer 80mm with Gal Tie Wire 15 1400
111691 Concrete Spacer 85mm with Gal Tie Wire 15 1400
111015 Concrete Spacer 90mm with Gal Tie Wire 15 1200
111693 Concrete Spacer 95mm with Gal Tie Wire 15 1200
111664 Concrete Spacer 100mm with Gal Tie Wire 15 1200

Key features and benefits

  • Fibre-reinforced concrete offers ≥ 60 MPa strength for structural-grade applications
  • Galvanised tie wire ensures firm attachment to rebar
  • Square concrete spacer profile with tapered design for self-locking stability
  • Cover sizes range from 20mm to 100mm, supporting diverse project requirements
  • Flat base distributes weight and prevents sinking on soft surfaces
  • AS/NZS 2425:2015 compliant – meets Australian standards for concrete spacers
  • Minimal risk of steel exposure or cracking due to precise alignment
  • Ideal for use as a concrete aspro in civil infrastructure and thermal exposure zones
  • NATA-certified strength and compliance testing ensures performance integrity
