Hy-Rib®

Hy-Rib high ribbed permanent sacrificial formwork sheet for concrete construction.
Reinforcement setup with Hy-Rib® sacrificial formwork installed for a concrete construction joint on a building site.
Hy-Rib® expanded metal sacrificial formwork showing ribbed mesh used as stay in place permanent formwork for construction joint formwork and concrete structures.

Hy-Rib®

Hy-Rib® is a high-strength sacrificial formwork system designed to deliver clean and reliable results in concrete construction. Manufactured from galvanised expanded metal, it provides excellent rigidity, strong aggregate interlock, and dependable performance as stay in place permanent formwork. Its open-mesh profile maintains visibility during pouring, allowing teams to monitor concrete flow and reduce the risk of voids or honeycombing.

Hy-Rib® is available in 0.4mm X 445mm X 2200mm, offering consistent structural properties for construction joint formwork, walls, slabs, beams and other concrete formwork applications. Its ribbed design minimises formwork pressure, removes the need for scabbling and speeds up installation across civil, commercial and infrastructure projects. Compliant with AU and NZ standards, Hy-rib® provides a safe, economical and long-lasting permanent formwork solution for demanding construction environments.

Download Hy-Rib® Brochure
Download Technical Data Sheet

SKU: 101786 Categories: ,

Specification

Product Code Description Pack Qty
101786 Grade 2811 0.4mm X 445mm X 2200mm 100

Key features and benefits

  • Aggregate Interlock: Ensures well-compacted concrete for maximum strength and durability.
  • Reduced Surface Preparation: Eliminates the need for scabbling, streamlining joint preparation and reinforcement work.
  • Enhanced Joint Strength: Delivers superior shear and flexural resistance in construction joints.
  • Visual Monitoring: Allows inspection during pours to prevent voids and honeycombing.
  • Versatility: Adapts to horizontal and vertical applications in formwork systems.
  • Economic Efficiency: Reduces labour, accelerates pouring, and minimises formwork pressure.
  • Safety Compliance: Minimises risks like Hand-Arm Vibration Syndrome, ensuring safer handling.
  • Durability: Galvanised material provides resistance to corrosion and ensures long-lasting performance.
